Tear-Resistant Woven Geotextile Fabric for Railway Applications
1
2
3
4
5
6
Place of Origin :China
Brand Name :Honghuan
Model Number :MWG
MOQ :100
Material :PP
Weight :100-800g/m2
Length :50-100m
Width :2-6m
Tensile Strength MD :38.5-105.1 kN/m
Tensile Strength CD :35.9-96.3 kN/m
Elongation MD :25%
Elongation CD :25%
Tensile Strength 2% MD :7-21 kN/m
Tensile Strength 2% CD :8.6-25 kN/m
Tensile Strength 5% MD :17.7-52.5 kN/m
Tensile Strength 5% CD :19.8-53 kN/m
Factory Seam Strength :18.4-52.5 kN/m
Apparent Opening Size :0.43-0.6 mm
Permittivity :0.04-0.9 sec-1
Contact Now
Product Description
Woven Geotextile MWG®
Mono-filament Woven Geotextile, which incorporate round strands that are extruded. It is composed of high-tenacity polypropylene yarns, which are woven into a network such that the yarns retain their relative position. Mono-filament woven geotextile is preferred for applications where both strength and filtration are a concern, such as shoreline rip rap applications.
Product Specifications
PROPERTIES
TEST METHOD
UNIT
MINIMUM AVERAGE VALUE
MWG270
MWG370
MWG570
MWG665
MWG770
Tensile Strength , MD
ASTM D 4595
kN/m
38.5
52.5
70
70
105.1
Tensile Strength , CD
ASTM D 4595
kN/m
35.9
47.3
70
96.3
84
Elongation, MD
ASTM D 4595
%
25
25
25
25
25
Elongation, CD
ASTM D 4595
%
25
25
25
25
25
Tensile Strength at
2%, MD
ASTM D 4595
kN/m
7
11
14
17.5
21
2%, CD
ASTM D 4595
kN/m
8.6
12.3
19.3
25
22.8
5%, MD
ASTM D 4595
kN/m
17.7
21.9
35
35
52.5
5%, CD
ASTM D 4595
kN/m
19.8
22.8
39.4
53
47.1
Factory Seam Strength
ASTM D 4884
kN/m
18.4
25.1
37.5
52.5
43.8
Apparent Opening Size
ASTM D 4751
mm
0.6
0.43
0.6
0.43
0.6
Permittivity
ASTM D 4491
sec-1
0.7
0.9
0.4
0.26
0.04
Water Flow Rate
ASTM D 4491
l/min/m2
2037
1630
1222
815
611
UV Resistance (% retained after 500 hours)
ASTM D 4355
%
80
80
80
70
80
NOTES:
·The values given are Minimum Average Values except elongation and UV resistance. Elongation is a Maximum Value and UV is a typical value.
·Mass per unit area has a tolerance of ±10%.
This information is provided for reference purposes only and is not intended as a warranty or guarantee. Ningbo HongHuan assumes no liability in connection with the use of this information. Specifications subject to change without notice.
Applications
1. Weed block for landscaped garden beds
2. Permeable liners for planters (stops soil erosion)
3. Weed control under wooden decking
4. Geotextile for separating aggregate / soils under walkway blocks or bricks
5. Assists in preventing paving from settling unevenly
6. Landscape fabric prevents soil erosion
more
